Long Range Uhf Rfid Flexible Anti-metal Tag For Asset tracking
UHF flexible anti-metal tags are widely used in logistics, warehousing, manufacturing, aerospace, automotive and other industries that require contact with metal surfaces. They can be used to track inventory, manage assets, and visualize the logistics chain.
RFID asset management Soft flexible Anti-Metal Tag can help companies keep track of what assets are whereby linking a specific item to a specific location. they will do that easily, often without a requirement to examine individual items. RFID systems also can help improve accountability for asset checks by identifying just which staffer checked an item during a particular location.they will also monitor the removal of assets from a site.
Features:
● Strong anti-fouling and anti-damage, work for long time
●High security, large capacity of writable information
●No contact, no need to be visible, fully automatic identification
● It can identify multiple tags at the same time at a long distance, saving time and effort.
● Anti-counterfeiting, anti-theft, tracking
Product Description
Logo Printing, Full color pre-printing, QR Code printing,
Barcode printing, Encoding, ect.
Flexible On metal tag can be used in asset management, Electronics,
Metal Equipment management and inventory. Solving the problem that the label on the metal can’t be read
Base Material
PET/Foam/Aluminum foil
Size
55*15*1.25mm（other size:65*35*1.25mm/ 70*30*1.2mm/ 80*40*1.0mm/customized ）
Frequency
860MHz-960MHz
Protocol
ISO/IEC 18000-6C, EPC G1 G2
Chip
Impinj Monza R6A
Memory
EPC:96Bits
Chip Life
100,000 Programming cycles50 years data retention
Operation Mode
Passive
Working Temperature
-20℃~+85 ℃
Storage Temperature
-20℃~+85 ℃
Data Conservation
10years
Personalization
Application
Product Show
Product Process
Application
Packaging
