RFID Label Anti-fake Tamper Proof RFID Windshield Sticker UHF Vehicle Label Tag
RFID Windshield Vehicle Tags are designed for automatic vehicle identification applications, such as electronic toll collection, electronic vehicle registration or parking, security access and fleet management.
Product Description
Protocol |
ISO/IEC 18000-6C; EPC Class1 Gen2 |
Frequency |
860~960MHz |
Chip |
H9 |
Surface Material |
Coated Paper/ PET/PVC/PP/customization |
Working Mode |
Passive |
IC Life |
100,000 Programming cycles, 10 years data retention |
Operating temperature/humidity |
-25~50℃/20%~80% RH |
Storage temperature/humidity |
+23°C±5°C/ 50%±10% RH (Without condensation). |
Antenna |
Aluminum Etching, 93*19mm |
Wet inlay/Label Size |
97*22mm or customization |
Printing |
Full Color Printing, Logo, Barcode, QR code, etc |
Sample |
Sample is free for your quality test |
Application |
Supply chain management, logistics and distribution product verification Vehicle management, ETC pass way luggage tracking, asset tracking authentication and serialization etc |
Product Show
What are the Dry Inlay/ Wet Inlay/ Labels?
RFID Dry Inlay
Inlay is a special term for RFID industry, which refers to a pre laminated product composed of multi-layer PVC or other materials containing chips and coils. After different forms of packaging, different kinds of RFID tags can be made. Inlay can be understood as semi-finished products without encapsulation of RFID tags.
RFID Dry inlay does not contain back glue, and its structure is antenna + chip + chip package; Frequency requirements: 860-960MHz-uhf / 13.56MHz-iso14443 / 13.56MHz-iso15693. RZX has technicians and offer antenna design service to meet various customer requirements.
RFID RFID Wet Inlay
RFID Wet inlay contains back glue, which can be directly attached to objects. The structure is antenna + chip + chip package + glue + release paper, if no logo print, customer can use the rfid wet inlay directly without make it as white/ printed label for cost saving. Frequency requirements: 860-960MHz-uhf / 13.56MHz-iso14443 / 13.56MHz-iso15693.
RZX has technicians and offer antenna design service to meet various customer requirements.
RFID Label
RFID white label, RFID sticker contains both back glue and top coated paper or PET, the structure is Coated paper/PET+antenna + chip + chip package + glue + release paper. RFID label packaging can be divided into fold, roll and single product. Products can be divided into thermal printing and heat transfer printing; materials can be paper, waterproof materials and PVC or PET for choice, size diversity for customers to choose, encryption processing, personalized and coding services, thermal printing full package; frequency requirements: 860-960MHz-uhf / 13.56MHz-iso14443 / 13.56MHz-iso15693.
More details or any question can contact Meihe directly.
What Is RFID Tag?
A Radio Frequency Identification Tag (RFID tag) is an electronic tag that exchanges data with a RFID reader through radio waves. Most RFID tags are made up of at least two main parts. The first is an an antenna, which receives radio frequency (RF) waves. The second is an integrated circuit (IC), which is used for processing and storing data, as well as modulating and demodulating the radio waves received/sent by the antenna.
1. Reader transfers energy to the transponder by emitting electromagnetic waves through air.
Application
